Technical Parameters
Technical Specifications:
Weight Capacity: 180kg (397 lbs) static load
Product Weight: 78kg (complete set with mattress)
Frame Construction: 4×6cm heavy-duty steel tubing with 1cm wall thickness at critical points
Overall Dimensions: 2130mm × 1020mm × 450mm (L×W×H)
Mattress Platform: 1900mm × 900mm × 70mm (steel band construction)
Backrest Adjustment: 0-75° manual operation with industrial-grade crank mechanism
Leg Elevation: 0-20° manual operation with synchronized movement
Bed Surface Construction: 1.2cm wide steel pipes with 1mm wall thickness, 10cm wide steel bands
Guardrail System: Removable steel core guardrails with padded covers, tool-free operation
Caster System: Four 100mm diameter medical-grade casters (two with central locking brake), 360° rotation
Headboard/Footboard: Solid wood panels with removable design, non-toxic finishes
Material Specifications:
Primary Frame: Q235B cold-rolled steel, 1.0-1.5mm wall thickness, powder coated finish
Wooden Components: Solid rubberwood (Hevea brasiliensis) with FSC certification, kiln-dried to 8-10% moisture content
Mattress: High-density foam core (30D density), waterproof anti-microbial vinyl cover, removable for cleaning
Hardware: Stainless steel grade 304 fasteners, zinc-plated moving components
Surface Finishes: Automotive-grade powder coating for steel components, water-based sealants for wooden parts
Performance Standards:
Durability Testing: 50,000 cycle fatigue testing on all crank mechanisms and moving parts
Load Testing: 200kg static load capacity verification with 1.25 safety factor
Safety Compliance: CE marking per MDD 93/42/EEC, ISO13485:2016 certified manufacturing, ANSI/BIFMA X5.1 standards
Environmental Rating: Operating temperature -10°C to +50°C, humidity tolerance up to 85% RH
Noise Level: <30dB during operation at 1 meter distance
Stability Testing: Meets IEC 60601-2-52 requirements for medical bed stability
Assembly Time: 15-20 minutes with two persons, tool-free design
Available Configurations:
Single Crank Model: Combined backrest and leg elevation control
Dual Crank Model: Independent backrest and leg elevation controls
Standard Model: Basic configuration with essential accessories
Premium Model: Enhanced features including upgraded mattress, additional accessories
Included Accessories:
Manual crank handles (1 or 2 pieces depending on model) with wall mounting brackets
Removable steel guardrails with padded covers (pair)
Solid wood headboard and footboard panels
High-density foam mattress with waterproof cover
Telescopic IV pole with height adjustment (800-1200mm)
Dual dining tables: solid wood table and ABS plastic table
Four 100mm medical-grade casters with central locking mechanism
Tool kit with Allen wrenches and installation manual
User manual and maintenance guide (multilingual)
Packaging Information:
Main Frame Carton: 2150mm × 1050mm × 300mm, weight 42kg
Wooden Components Carton: 800mm × 600mm × 150mm (headboard, footboard, tables), weight 15kg
Mattress Carton: 1950mm × 950mm × 200mm, weight 18kg
Accessories Carton: 600mm × 500mm × 400mm (cranks, guardrails, IV pole, hardware), weight 10kg
Gross Weight per Complete Set: 85kg
Packaging Standards: ISTA 3A certified, moisture-proof treatment, barcoded for inventory tracking
Container Loading: 75 sets per 40HQ container (96% space utilization)
Application Environments:
General hospitals and acute care facilities
Long-term care facilities and nursing homes
Rehabilitation centers and physical therapy clinics
Home healthcare and palliative care settings
Senior living communities and assisted living facilities
Government health ministries and public healthcare systems
Military field hospitals and disaster relief operations
Medical equipment rental and leasing companies
Product Advantage
Industrial-Grade Structural Integrity
Engineered for maximum durability and patient safety, our nursing bed features a comprehensive structural system that exceeds international medical equipment standards. The primary frame utilizes 4×6cm heavy-duty steel tubing with 1cm wall thickness at critical load-bearing points, providing exceptional stability and supporting 180kg static load capacity with a 1.5 safety factor. The bed surface construction employs 1.2cm wide steel pipes with 1mm wall thickness welded in a reinforced grid pattern, combined with 10cm wide steel bands that distribute weight evenly across the entire platform. This industrial-grade engineering eliminates frame flexing and noise during patient movement, while the powder-coated finish provides superior corrosion resistance against hospital cleaning chemicals and high-humidity environments. Unlike conventional beds that use thinner materials, this robust construction ensures 10+ year service life even in high-traffic institutional settings, significantly reducing replacement costs and maintenance downtime for healthcare facilities.
Advanced Manual Positioning System
Our precision-engineered crank mechanism delivers smooth, reliable operation without electrical dependencies, making it ideal for regions with unstable power supplies and budget-conscious facilities. The dual-crank system provides independent control of backrest adjustment (0-75°) and leg elevation (0-20°) with industrial-grade steel gears that require minimal force to operate, enabling caregivers to position patients with ease while reducing physical strain. The backrest mechanism features anti-shear geometry that prevents dangerous patient sliding during elevation, maintaining proper spinal alignment and reducing pressure ulcer risk by 40% compared to standard beds. The leg elevation function promotes healthy blood circulation and prevents muscle atrophy in bedridden patients, with smooth operation that eliminates jerky movements that could cause discomfort or injury. The crank handles feature ergonomic grips with foldable design that stores flush against the frame when not in use, preventing protrusion hazards and optimizing space utilization in crowded patient rooms.
Professional Caregiver Efficiency Features
Designed through extensive collaboration with nursing professionals, this bed transforms daily care workflows while reducing physical strain and operational costs. The dual dining table system includes both wooden and ABS options that accommodate different care scenarios – the wooden table provides warm, residential aesthetics for meals and social activities, while the ABS table offers easy-clean surfaces for medical procedures and medication administration. The adjustable IV pole mounts directly to the bed frame via dedicated sockets, eliminating trip hazards from freestanding poles and ensuring medication delivery stability during position changes. The four heavy-duty casters with central locking mechanism provide 360° mobility with whisper-quiet operation (<30dB) and absolute stability during patient transfers, while the removable guardrails offer fall protection without compromising nursing access. The modular design allows tool-free assembly and component replacement, reducing installation time by 50% and minimizing facility downtime during equipment maintenance.
Comprehensive Patient Comfort and Safety System
Every aspect of this bed prioritizes patient dignity and safety through thoughtful engineering and premium materials. The solid wood headboard and footboard panels provide warm, non-institutional aesthetics that reduce patient anxiety while maintaining professional durability, with rounded edges and smooth finishes that prevent injury during transfers. The therapeutic mattress features high-density foam construction with waterproof, anti-microbial covering that prevents bacterial growth and simplifies cleaning after incontinence incidents. The guardrail system employs steel cores with comfortable padding that provides secure fall protection while maintaining a homely appearance that doesn't compromise room aesthetics. The bed's dimensions (213×102cm) fit standard patient rooms while providing ample space for comfortable positioning, and the 45cm fixed height optimizes ergonomic access for caregivers while reducing fall risks for semi-mobile patients. All moving parts undergo 50,000-cycle durability testing to ensure smooth operation throughout the product lifecycle, and the entire system complies with CE and ISO13485 safety standards for medical equipment.
Product Uses
General Hospitals and Acute Care Facilities
In high-acuity hospital environments, this manual nursing bed transforms patient care delivery while reducing staff injury rates and operational costs. The 0-75° backrest adjustment enables optimal positioning for respiratory therapy, feeding procedures, and patient comfort during extended bed rest, while the 0-20° leg elevation function supports circulatory improvement and pressure ulcer prevention protocols. The dual dining table system accommodates both medical procedures (ABS table) and family meal times (wooden table), enhancing patient dignity and family engagement during hospitalization. The central locking caster system maintains absolute stability during critical procedures while enabling rapid room reconfiguration for emergency responses and infection control protocols. Hospital administrators particularly value the reduced maintenance costs – with no electrical components to fail, this manual system offers 80% lower lifetime ownership costs compared to electric beds while maintaining 99.9% operational reliability even during power outages. The robust steel construction withstands aggressive cleaning protocols and 24/7 usage in high-traffic wards, and the modular design allows partial replacement of worn components without complete bed replacement, significantly reducing equipment downtime and replacement costs.
Long-Term Care Facilities and Nursing Homes
For senior care institutions managing high patient volumes, this manual nursing bed significantly enhances quality of life while reducing operational expenses. The intuitive crank system empowers caregivers with minimal training to safely position residents for feeding, hygiene routines, and pressure relief without requiring electrical expertise or expensive service calls. The dual dining tables enable residents to enjoy meals in comfortable upright positions, promoting social interaction and digestive health while reducing aspiration risks. The removable guardrails provide overnight safety for residents with dementia or mobility issues while maintaining a homelike appearance that doesn't create institutional sterility. The heavy-duty steel frame withstands constant use in 24/7 care environments, with the powder-coated finish resisting damage from frequent cleaning chemicals and the caster system maintaining smooth operation despite continuous movement. Facility directors report 35% reduction in equipment replacement costs and 25% decrease in staff injury claims related to patient handling, making this bed a cost-effective investment with measurable ROI in both resident satisfaction scores and operational efficiency metrics. The warm wooden components create a welcoming environment that reduces resident anxiety and improves compliance with care protocols.
Home Healthcare and Palliative Care Settings
In residential care environments, this manual nursing bed bridges the gap between clinical functionality and home comfort. The robust 1cm thick steel frame provides hospital-grade reliability while the wooden headboard and dining table create a warm, non-institutional atmosphere that preserves patient dignity and reduces psychological stress during long-term care. The manual crank system enables family caregivers with minimal medical training to safely position loved ones for feeding, medication administration, and pressure relief routines without requiring electrical expertise or expensive service calls. The dual dining table options accommodate both medical needs (ABS table for medication administration) and family activities (wooden table for shared meals), enhancing quality of life and family bonding during home care periods. The compact footprint fits standard bedroom spaces while delivering professional care capabilities, and the removable guardrails provide safety without creating prison-like aesthetics that compromise home environment quality. For home health agencies, this bed enables professional-level care delivery in residential settings, reducing hospital readmissions by 30% through improved pressure ulcer prevention and enhanced patient comfort, while the tool-free assembly design allows quick installation in homes with limited access or space constraints.
Rehabilitation Centers and Physical Therapy Clinics
In therapeutic environments, this versatile bed serves as a foundational rehabilitation tool that supports progressive recovery protocols. The precise 0-75° backrest adjustment facilitates respiratory therapy sessions and comfortable positioning during extended treatment periods, while the 0-20° leg elevation function supports circulatory improvement exercises for patients recovering from strokes, spinal injuries, or orthopedic surgeries. Physical therapists appreciate the smooth manual operation that allows gradual position changes without startling sensitive patients, and the sturdy construction accommodates various therapeutic equipment attachments and aggressive positioning techniques without structural compromise. The wooden dining table provides a stable surface for occupational therapy activities and fine motor skill development, while the ABS table accommodates medical equipment during therapy sessions. The elevated bed height optimizes therapist ergonomics during manual handling procedures, reducing workplace injuries and improving treatment effectiveness. The removable guardrails create unobstructed access for specialized therapy equipment, and the quiet caster system maintains focused treatment environments without disruptive mechanical noises. For rehabilitation facility directors, the manual system's reliability and low maintenance requirements translate to higher equipment utilization rates and better return on investment compared to electric alternatives that require frequent servicing and expensive parts replacement.
FAQ
Q1: What international safety certifications does this manual nursing bed have?
A: This manual single/dual crank nursing bed complies with comprehensive international standards including CE marking under MDD 93/42/EEC, ISO13485:2016 medical device quality management, ANSI/BIFMA X5.1 institutional furniture standards, and ISO 7176-19 wheelchair seating requirements. It has passed rigorous testing including 200kg static load capacity verification, 50,000-cycle durability testing on all mechanisms, material safety certifications for wooden components (FSC certification, low-VOC finishes), and stability testing per IEC 60601-2-52. We provide complete certification documentation including test reports from SGS/TÜV laboratories, material safety data sheets, and quality control certificates for customs clearance in all major markets including EU, USA, Canada, Australia, and Middle East countries.
Q2: What is the warranty period and what after-sales support services are provided?
A: We offer comprehensive warranty coverage: 5-year warranty on structural components and frame, 3-year warranty on mechanical mechanisms (cranks, linkages), and 2-year warranty on accessories and moving parts. Our global after-sales network includes authorized service centers in 35+ countries with 48-hour response time for technical support and 3-5 day parts delivery for critical components. We provide detailed maintenance manuals, spare parts catalogs with exploded diagrams, and video tutorials for common repairs and adjustments. For bulk orders above 40 units, we offer on-site installation training and preventive maintenance programs at no additional cost. We maintain 7-year spare parts inventory guarantee and provide quarterly technical webinars for institutional customers.
Q3: How is the product packaged for international shipping and what are the container loading specifications?
A: Each nursing bed is professionally packaged in reinforced export cartons with multi-layer protection: main bed frame in 2150×1050×300mm carton with internal foam corner protection and moisture-proof wrapping, wooden headboard/footboard in separate 800×600×150mm carton, mattress in 1950×950×200mm carton with waterproof barrier, and accessories kit (cranks, guardrails, IV pole, tables, hardware) in 600×500×400mm carton. Total gross weight per complete set: 85kg. We optimize packaging for container efficiency – 40HQ container holds 75 complete sets with 96% space utilization. All packaging meets ISTA 3A international shipping standards with clearly marked handling instructions, barcoding for inventory tracking, and multilingual assembly diagrams.
Q4: Can the product be customized for specific market requirements or institutional specifications?
A: Yes, we offer extensive customization options to meet diverse market needs. Technical customizations include dimensional modifications (length, width, height ranges), reinforced frames for bariatric applications (250-300kg capacity), specialized caster systems for different floor types (carpet, tile, concrete), and alternative crank handle designs for ergonomic preferences. Material customizations include different wood species (oak, beech, walnut) for headboards and tables, upgraded mattress configurations (high-density foam, anti-bacterial covers), and alternative guardrail designs (full-length, half-length, removable styles). For institutional customers, we can add custom branding, facility-specific safety features, or integrate with existing room layouts and equipment systems. Minimum order for customization is 30 units, with engineering consultation fees waived for orders above 100 units.
Q5: What is the minimum order quantity (MOQ) and typical lead time for bulk shipments?
A: Standard MOQ is 20 units for mixed configurations (different wood finishes/accessories). For exclusive distributor agreements in new markets, we offer flexible MOQ starting from 10 units with progressive pricing tiers based on volume commitments. Standard production lead time is 20-25 working days after order confirmation and deposit payment. For urgent orders, we maintain ready stock of 80 units with 7-day dispatch capability. Large volume orders (150+ units) receive priority production scheduling with guaranteed delivery timelines backed by contractual penalties for delays. We offer partial shipments to help customers manage cash flow and inventory space.
Q6: How does the bed perform in high-humidity tropical environments and what maintenance is required?
A: This nursing bed is specifically engineered for challenging environmental conditions including tropical climates. The steel frame features triple-layer anti-corrosion protection: zinc plating + epoxy primer + electrostatic powder coating with 1000+ hour salt spray resistance certified to ASTM B117 standards. The wooden components are kiln-dried to 8-10% moisture content and receive water-based sealants with anti-fungal treatment. Recommended maintenance includes monthly lubrication of moving parts with medical-grade silicone grease (provided in maintenance kit), quarterly inspection of structural bolts, and bi-annual cleaning of caster wheels. We provide detailed tropical climate maintenance manuals and the bed has been successfully deployed in Southeast Asia, Caribbean, and Middle East markets with zero corrosion-related failures over 3-year period.
Q7: What training and technical documentation is provided for healthcare facility staff?
A: We provide comprehensive training and documentation packages tailored for institutional use. Standard documentation includes: multilingual user manuals (English, Spanish, French, German, Arabic, Russian), detailed assembly guides with torque specifications, preventive maintenance schedules with lubrication points diagrams, troubleshooting flowcharts for common issues, and technical specifications sheets. Training resources include: step-by-step video tutorials covering all functions and safety procedures, interactive 3D assembly simulations accessible via QR codes, and downloadable PowerPoint presentations for staff training sessions. For orders above 30 units, we offer live virtual training sessions via Zoom/Teams with certified product specialists.
Q8: What payment terms and shipping options are available for international orders?
A: We offer flexible payment terms: 30% deposit with 70% balance before shipment (T/T), irrevocable letter of credit at sight (L/C), and for established partners with 2+ years cooperation, 60-day credit terms with trade credit insurance. Shipping options include FOB Shanghai/Ningbo ports, CIF to destination ports worldwide, and DDP door-to-door delivery with full customs clearance assistance. We partner with premium freight forwarders offering real-time shipment tracking, cargo insurance up to 110% of goods value, and dedicated customs brokers in major destination countries. For first-time customers, we provide detailed import duty calculation assistance and help prepare all required documentation.
